UJ7C1K21M Nidec 7 1/2 hp 3600 RPM 1-phase 215JM Frame 230V TEFC Close-Coupled Pump Motor
This Nidec close-coupled pump motor delivers 7 1/2 horsepower at 3600 RPM and is designed for single-phase 230V applications. It is ideal for replacing or upgrading pumps requiring a robust, totally enclosed fan-cooled motor with a 215JM rolled steel frame.
Key Specifications
Horsepower: 7 1/2 HP
RPM: 3600
Voltage: 230V, 60 Hz
Amperage: 30.3 amps
Enclosure: Totally Enclosed Fan Cooled (TEFC)
Frame / Diameter: NEMA 215JM Rolled Steel Frame
Shaft Dimensions: JM steel shaft
Rotation: Reversible
Bearings: Ball Bearings
Product Features & Fitment
This motor features a close-coupled design with the pump impeller mounted directly on the shaft, simplifying installation and reducing alignment issues. It includes a rigid base for stable mounting and is constructed with Class F insulation for enhanced thermal endurance. Thermal protection is not included.
