DH20S2HF Nidec 20 hp 1800 RPM 200V ODP 254T (Rigid Base) 3-Phase Dry Elevator Motor

Sale!
DH20S2HF Nidec 20 hp 1800 RPM 200V ODP 254T (Rigid Base) 3-Phase Dry Elevator Motor

DH20S2HF Nidec 20 hp 1800 RPM 200V ODP 254T (Rigid Base) 3-Phase Dry Elevator Motor

Original price was: $1,176.59.Current price is: $758.88.

56 in stock

SKU: DH20S2HF Category:

Description

  • 20 hp 1800 RPM, 58.0 amps 200 Volts 60 Hz Three Phase Motor
  • NEMA 254T Cast Iron End Bells, Keyed Shaft 1 5/8″ Diameter x 4″
  • Service Factor: 1.0 Overload protection = None, Intermittent Duty
  • Rigid Base Mount, Ball Bearings, Class F Insulation,
  • 1 Year Manufacture Warranty

For hydraulically driven elevators where motor remains dry. 72″ lead length. Wiring diagram on motor name plate. ODP = Open Drip Proof. HE93
